STARLAB

Sound Design

• Three selectable reverb types for a wide variety of ambient textures

• DELAY/KARPLUS section with feedback

• Delay assignable to output for mod/verb and delay/verb effects

• Four-octave Karplus-Strong string synthesis mode with damping control for string/verb full voice capability

• LFO section with various waveforms to modulate delay time, reverb size, or tone filters

• FILTER section to sculpt the high and low EQ of the reverb and DELAY/KARPLUS section

• HARMONICS section to enhance the aural spectrum of the reverb

• Adjustable SHIMMER for adding pitch shifting of up to +/- 1 octave to the reverb

• GLIMMER for dynamic enhancement of harmonics

• Adjustable reverb core size to increase or decrease the space for reflections, allowing for pitch control of the regenerating reverb content

• 4-pole 24dB/octave variable resonance low pass filter

• INFINITE freezes the input audio prior to the reverb tank

• Independent WET and DRY level controls

Ins, Outs, Switches

• Stereo inputs and outputs

• Extensive CV control of parameters

• Access to four presets from the front panel

• USB jack (located on the rear) for performing firmware updates

Audio Quality

• Analog dry path for a zero latency dry signal that is never converted to digital

• Ultra low noise, high performance 24-bit 96kHz A/D and D/A converters provide uncompromising audio quality

• Super high performance ARM DSP

• 32-bit floating point processing

Dimensions

• Rack width: 28hp

• Rack depth: 41mm, 1.61″

Power requirements

• +12V rail: 210mA

• -12V rail: 210mA

• +5V rail: 0mA

• Designed and built in the USA.
